型号 |
流量 |
扬程 (m) |
转速 (r/min) |
功率(kW) |
效率 (%) |
必需汽蚀余量 NPSH(r)(m) |
吐出锥管口径 (mm) |
||
|
m3/h |
l/s |
轴功率 |
配用功率 |
||||||
|
KTZ125-100-200 |
60 100 120 |
16.7 27.8 33.3 |
14.5 12.5 11 |
1450 |
3.84 4.48 4.79 |
7.5 |
26 76 75 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-200A |
56 93.5 112 |
15.6 26 31.1 |
12.8 11 9.7 |
1450 |
3.17 3.7 3.96 |
5.5 |
62 76 75 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-250 |
60 100 120 |
16.7 27.8 33.3 |
21.5 20 18.5 |
1450 |
5.59 7.17 7.84 |
11 |
62 76 77 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-250A |
56 93.5 112 |
15.6 26 31.1 |
18.8 17.5 16.2 |
1450 |
4.56 5.87 6.41 |
7.5 |
63 76 77 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-250B |
52.2 86.5 104 |
14.5 24 28.9 |
16 15 13.9 |
1450 |
3.7 4.86 5.17 |
5.5 |
62 75 76 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-315 |
60 100 120 |
16.7 27.8 33.3 |
33.5 32 30.5 |
1450 |
9.4 11.9 13.5 |
15 |
58 73 74 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-315A |
57.4 95.5 114 |
15.9 26.5 31.7 |
30.5 28.5 27.8 |
1450 |
8.22 10.33 11.7 |
15 |
58 73 74 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-315B |
54.6 90.8 108.9 |
15.1 25.2 30.3 |
27.7 26.4 25.8 |
1450 |
7.23 9.08 10.5 |
11 |
57 72 73 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-400 |
60 100 120 |
16.7 27.8 33.3 |
52 50 48.5 |
1480 |
16.1 21 23.6 |
30 |
53 65 67 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-400A |
56 93.6 112.4 |
15.6 26 31.2 |
46 44 43 |
1480 |
13.2 17.5 19.6 |
22 |
53 64 67 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-400B |
52.2 88 105 |
14.5 24.4 29.2 |
40 38 37.2 |
1480 |
11.2 14.6 16.4 |
18.5 |
51 62.8 65 |
2.5 2.5 3.0 |
100-125 |
|
KTZ125-100-210 |
90 142 170 |
25 39.4 47.2 |
15 13 11.5 |
1480 |
5.25 6.36 6.91 |
11 |
70 79 77 |
2.2 2.5 3.4 |
100-125 |
|
KTZ125-100-260 |
95 148 175 |
26.4 41.1 48.6 |
24.5 22 20 |
1480 |
9.19 11.37 12.54 |
15 |
69 78 76 |
2.3 2.6 3.5 |
100-125 |
|
KTZ125-100-320 |
80 146 165 |
22.2 40.6 45.8 |
37.5 34 29 |
1480 |
12.73 16.7 18.38 |
22 |
65 75 72 |
2.0 2.0 2.3 |
100-125 |
|
KTZ125-100-320A |
78 142 165 |
21.7 39.4 45.8 |
32 28 25 |
1480 |
10.8 14.83 16.28 |
18.5 |
63 73 69 |
2.0 2.0 2.3 |
100-125 |
|
KTZ125-100-410 |
90 150 176 |
25 41.7 48.9 |
57 52 48.5 |
1480 |
24.09 31.24 34.96 |
45 |
58 68 67 |
2.3 2.5 3.2 |
100-125 |
|
KTZ125-100-410A |
87 144 172 |
24.2 40 47.8 |
52 48 44 |
1480 |
22 28.5 31.7 |
37 |
56 66 65 |
2.3 2.5 3.2 |
100-125 |
|
KTZ125-100-410B |
83 140 165 |
23.1 38.9 45.8 |
45 40 38 |
1480 |
18.83 23.8 27.1 |
30 |
54 64 63 |
2.3 2.5 3.2 |
100-125 |
|
KTZ150-125-250 |
120 200 240 |
33.3 55.6 66.7 |
22.5 20 17.5 |
1480 |
10.4 13.5 14.7 |
18.5 |
71 81 78 |
3.0 3.0 3.5 |
125-150 |
|
KTZ150-125-250A |
112 187 224 |
31.1 51.9 62.2 |
19.5 17.5 15.2 |
1480 |
8.7 11.3 12.3 |
15 |
68 77.9 75.3 |
3.0 3.0 3.5 |
125-150 |
|
KTZ150-125-260 |
144 240 288 |
40 66.7 80 |
23.5 21 18.1 |
1480 |
13.17 16.95 18.9 |
22 |
70 81 78 |
2.3 2.6 3.2 |
125-150 |
|
KTZ150-125-260A |
134 230 280 |
37.2 63.9 77.8 |
21 18.5 16.5 |
1480 |
11.43 14.66 16.55 |
18.5 |
67 79 76 |
2.3 2.6 3.2 |
125-150 |
|
KTZ150-125-315 |
120 200 240 |
33.3 55.6 66.7 |
34 32 29 |
1480 |
15.86 22.08 23.71 |
30 |
70 79 80 |
2.5 2.5 3.0 |
125-150 |
|
KTZ150-125-315A |
112 187 224.6 |
31.1 51.9 62.4 |
30 28 25 |
1480 |
13.1 18.1 19.1 |
22 |
70 79 80 |
2.5 2.5 3.0 |
125-150 |
|
KTZ150-125-315B |
104 173 208 |
28.9 48.1 57.8 |
25.5 24 21.8 |
1480 |
10.5 14.5 15.6 |
18.5 |
69 78 79 |
2.5 2.5 3.0 |
125-150 |
|
KTZ150-125-320 |
144 240 288 |
40 66.7 80 |
34 32 28 |
1480 |
19.05 26.47 27.45 |
30 |
70 79 80 |
2.5 2.5 3.0 |
125-150 |
|
KTZ150-125-320A |
134 230 270 |
37.2 63.9 75 |
29 26 22 |
1480 |
15.79 20.61 21.01 |
22 |
67 79 77 |
2.5 2.5 3.0 |
125-150 |
|
KTZ150-125-400 |
120 200 240 |
33.3 55.6 66.7 |
53 50 46 |
1480 |
27.9 36.3 40.6 |
45 |
62 75 74 |
2.0 2.8 3.5 |
125-150 |
|
KTZ150-125-400A |
112 187 225 |
31.1 51.9 62.5 |
47 44 40 |
1480 |
23.2 30 33.1 |
37 |
62 75 74 |
2.0 2.8 3.5 |
125-150 |
|
KTZ150-125-400B |
105 173 210 |
29.2 48.1 58.3 |
40 38 35 |
1480 |
18.7 24.4 27.4 |
30 |
61 74 73 |
2.0 2.8 3.5 |
125-150 |
|
KTZ150-125-410 |
144 245 300 |
40 68.1 83.3 |
55 50 44 |
1480 |
32.68 43.9 49.9 |
55 |
66 76 72 |
2.2 2.4 3.2 |
125-150 |
